Mast Assembly - PN 131787 Parts List
PN 131787
ITEM PART DESCRIPTION QTY
1 106542 MAST 76 HSS 1
2 125254 VB 4 SECT W/PROP DELTROL 8GPM V2 1
3 107774 WINCH 3750 TI2CC W/120 FT ROPE 1
4 27813 COLLAR 0.38X0.75X0.38 UHMW 2
5 C5902 WASHER 0.63 SAE FLAT YELLOW GR8 22
6 66838 CAP SCR 0.63-11X2.50 HHGR8 W/RED PATCH 14
7 0343 WASHER 0.31 USS FLAT 4
8 0491 CAP SCR 0.31-18X4.00 HHGR5 2
9 0342 NUT 0.31-18 HHGR5 NYLOC 2
10 57594 BUSHING COMPOSITE 2.00X0.50 4
11 D0894 CAP SCR #10-24X0.75 BTNHD SS 4
12 0333 NUT 0.25-20 HHGR5 NYLOC 6
13 0340 WASHER 0.25 USS FLAT 12
14 0437 CAP SCR 0.25-20X1.25 HHGR5 6
15 101846 PLATE RADIO MNT MAST 76 HSS 1
16 84053 CAP SCR 0.63-11X2.25 HHGR8 4
17 24868 NUT 0.63-11 HHGR8 NYLOC 4
18 D0178 WASHER #10 SAE FLAT 4
19 26034 NUT #10-24 HH NYLOC 4
INITIAL RELEASE
NOTES:
HARDWARE KITS:
118557
118558
