7630 Telescopic Crane Owner’s Manual PN: 106864| Page 47

Extension Cylinder Assembly - PN 103416 Parts List

PN 103416

ITEM PART DESCRIPTION QTY

1 103417 CYLINDER EXT 7630 HSS 2 STAGE 2.0/2.0 1

2 107507 TUBE ASM 0.38X120.86 EXT CYL 7630 HSS 1

3 107508 TUBE ASM 0.38X87.63 EXT CYL 7630 HSS 1

4 D0655 HOSE CLAMP #36 WRM GEAR 3

5 0481 CAP SCR 0.25-20X2.00 HHGR5 3

6 106830 MANIFOLD ASM 76 HSS EXT CBBD-LJN-XVN CUSTOM 1

7 4543 CAP SCR 0.75-10X2.00 HHGR8 1

8 C6219 WASHER 0.75 SAE FLAT YELLOW GR8 1

NOTE:

C-BALANCE VALVE: 9803

CYLINDER SEAL KITS:

BOB: 80503

COL: 128727

BMF: 129549

HARDWARE KIT: 118871
