7630 Telescopic Crane Owner’s Manual PN: 106864| Page 45
Main Cylinder Assembly - PN 113682 Parts List
PN 113682
ITEM PART DESCRIPTION QTY
1 71164 CYLINDER 4.50X22.50 1
2 279 FTG 6-6 MFS-MORB STRAIGHT 5
3 71460 TUBE ASM 0.38X16.72 12630 MAIN CYL ZC 1
4 113695 MANIFOLD SINGLE LA C’BAL W/PRV 1
5 33743 FTG 6-6 FFSS-MORB STRAIGHT 1
6 3861 FTG 6-6 MAORB-FORB 90 2
7 15111 FTG 6-4 MORB-FORB STRAIGHT REDUCER 2
8 108268 TRANSDUCER PRESSURE 0-5000PSI #4 SAE DT 2
NOTES:
C-BALANCE VALVE: 113696
PRESSURE REDUCING VALVE: 35454
CYLINDER SEAL KITS:
BOB-91064
COL-129795
BMF-129796
BUSHING PART NUMBER: 4381
BUSHINGS INCLUDED IN 71164
HARDWARE KIT: 98191
