7630 Telescopic Crane Owner’s Manual PN: 106864| Page 2
Model 7630 Specications
SPECIFICATIONS
CRANE RATING* 44,840 FT-LBS (6.2 TM)
STANDARD BOOM LENGTH 13’ 0” (3.96 M) FROM CL OF CRANE
BOOM EXTENSION:
1ST STAGE: HYDRAULIC 100” (254 CM)
2ND STAGE: HYDRAULIC 100” (254 CM)
MAXIMUM HORIZONTAL REACH: 29’ 8” (9.04 M) FROM CL OF CRANE
MAXIMUM VERTICAL LIFT 31’ 6” (9.6 M) FROM CRANE BASE
STOWED HEIGHT (CRANE ONLY) 38.6” (98 CM)
REQUIRED MOUNTING SPACE 20” X 21” (50.8 CM X 53.3 CM)
APPROXIMATE CRANE WEIGHT 7630 HSS STANDARD: 1715 LBS (778 KG)
CONTROLS RADIO CONTROL STANDARD FOR ALL FUNCTIONS.
WIRE ROPE 3/8” (0.95 CM)6X31 IWRC-DGXIP X 120’ (36.58 M)
BOOM ELEVATION -10º TO +80º
WINCH SPECIFICATIONS
LINE PULL SPEED: 60 FT / MIN (18.29 M / MIN)
MAX. SINGLE PART LINE: 3,750 LBS (1,700 KG)
MAX. DOUBLE PART LINE 7,500 LBS (3,400 KG)
ROTATION (WORM GEAR): 400º POWER
LIFTING CAPACITY**
7,500 LBS @ 5’10” (3,400 KG @ 1.78 M)
2,135 LBS @ 21’ (965 KG @ 6.40 M)
POWER SUPPLY
PTO & PUMP: 8 GPM @ 3,000 PSI
(30.3 LPM @ 207 BAR)
NOTES:
*CRANE RATING IN BOOST MODE. NORMAL CRANE RATING IS 38,000 FT-LBS (5.25 TM).
**MAXIMUM CAPACITIES IN BOOST MODE.
