Page 44 | Stellar
®
7630 Telescopic Crane Owner’s Manual PN: 106864
Main Cylinder Assembly - PN 113682
5
1
NUMBER LOCATION
2
3
4
6
7
8
2
2
CYLINDER SERIAL
2
NOTES:
C-BALANCE VALVE: 113696
PRESSURE REDUCING VALVE: 35454
CYLINDER SEAL KITS:
BOB-91064
COL-129795
BMF-129796
BUSHING PART NUMBER: 4381
BUSHINGS INCLUDED IN 71164
HARDWARE KIT: 98191
