Page 11
ASSEMBLY KITS- BILL OF MATERIALS
QTY PART NUMBER DESCRIPTION
4 09-0013 3M Grip tape
28 60-0014 6-32 Nylock nut
28 60-0156 6-32 x 2” SS Pan head screw
8 halves 10-1155-01 Glass filled plastic sweep couplers
40/30 Loop Hardware Kit
72-0030-61
QTY PART NUMBER DESCRIPTION
9 60-0029 ¼-20 X 3” Stainless steel hex bolt
30 60-0041 1/4” Stainless steel washer
1 60-0037-21 5/16” x 4” Eyebolt S/S
2 60-0046 5/16” Nylock nut
9 60-0030 1/4” - 20 Nylock nut
1 60-0103 3” x 5/16” Hex head bolt
3 60-0033 5/16” Flat washer
Boom Assembly Kit
72-0035-02
