Tech Support: www.steppir.com/support Tel: 425.891.6134 support@steppir.com
Page 2
Specifications DB18 Yagi
Boom length 19 ft / 5.79 m
Boom outside diameter 1.75 in—2 in / 4.45—5.08 cm
Longest element 39 ft / 11.9 m
Turning radius 21.58 ft / 6.57 m
Weight 96 lb / 43.5 kg
Wind load 10.1 sq ft / 0.93 sq m
Wind rating 100 mph
Adjustable elements 3
Power Rating 3000 watts continuous
Feed points 3
Frequency coverage 6.8 MHz—54 MHz
Control cable 16 conductor shielded, 22AWG
Frequency Gain, dBi Front to rear, dB
40M 6.2 20
30M 5.4 NA
20M 7.4 25
17M 8.3 25
15M 8.5 20
12M 8.8 15
10M 9.0 11
6M 6.2 4
6M w/passive opt. 10.1 30
DB18 Yagi Specifications
DB18 Yagi w / 6m passive option
PREAMBLE
