Page 9
DB18 PARTS CHECKLIST
QTY Part # Description
1 70-3401-01 20m Driven element EHU, no relay (no lid - mounting plates acts as lid)
2 70-3406-01 DB18 40m Driven w/ normal passive relay (no lid, mounting plate acts as lid)
1 SDA100 Electronic controller
Options for SDA100:
1 01321 Transceiver interface
1 01324 Remote driver board
1 01323 Advanced lightning protection (ALP)
1 01322 Tuning relay
1 Power supply 24v___ (PN 09001) 33v___ (PN 09002)
EHU Control cable wire pack consisting of:
1 Length 10ft 6 inch four conductor cable
1 Length 20 ft 6 inch piece of six conductor cable (for EHU's with relays)
1 Coax seal (used to seal the control cable in the wire trough of EHU)
10 10-1013-02 18 ft telescoping fiberglass pole
1 71-0008 DB18 Instruction manual
1 71-0010 SDA 100 Instruction manual
1 09-0007 Blue silicone wrap (40/30 pole tip prep)
1 09-1025 11/16" Conical grinding stone (40/30 pole tip prep)
2 70-1007-01 Foam plug assembly (20m pole tips)
10 60-1006-22 Quick disconnect boot 1.5" x 1.25" (connect poles to EHU)
30 10-1059-01 Polyolefin heat shrink (waterproof telescoping pole joints)
1 20-6208-01 25 pin dSub connector (only used if no dsub splice purchased)
1 20-6209-01 Backshell for 25 pin dSub connector
4 10-1156-01 Plastic sweeps for 40/30 loop elements
1 10-1610-23 11.5" x 11.5" Mast plate
2 10-1608-01 Return plate for 40/30 loop
4 10-1503-21 Fiberglass sweep supports, black (connects between each sweep coupler)
2 10-1015-11 Return EST, 12" with reinforcing rings on each end
3 70-2030-01 EHU aluminum mounting plate with foam aligning gasket
1 03322 16 conductor control cable _______________ ft
1 70-3001-01 Aluminum coax switch box, with lid (lid has SO239 connectors mounted)
1 70-2037 Connector junction box
It is important that you do an inventory of the items that were shipped to you. Nothing is worse than
discovering a day before a planned installation that there are missing parts! We do our very best to en-
sure that you receive everything needed for construction of your antenna, but better to be safe than
sorry—inventory your parts well in advance of your installation. The items in blue represent options
available for the DB18 Yagi—you will need to check these items off only if you purchased them.
PREAMBLE
