6
Room temperature HC 1
With the menu item ROOM T HC1 you can
select the set room temperature for day and
setback mode for heating circuit 1. Changing
these parameters results in a parallel offset of
the heating curve.
The actual room temperature can also be
scanned, as soon as the FE 7 or FEK remote
control has been connected and allocated to
heating circuit 1.
DHW temperature
You can allocate a set day or night tempera-
ture to the DHW cylinder temperature using
the DHW TEMP menu item.
Open the control flap.
Open the control flap.
Room temperature HC 2
With the menu item ROOM T HC2 you can
select the set room temperature for day and
setback mode for heating circuit 2. You can
change the room temperature, if you feel
rooms are either too hot or too cold. ROOM
TEMP 2 will only be displayed, if the mixer
flow sensor is connected.
The actual room temperature can also be
scanned, as soon as the FE 7 or FEK remote
control has been connected and allocated to
heating circuit 2.
Open the control flap.
Adjustments at control level 2 for users and contractors
Room t HC1
SET Room t DAY
SET Room t DAY
SET Room t NGT
SET Room t NGT
ACTUAL Room t
Back
Room t HC1
Room t HC2
Set Roomt DAY
Set Roomt DAY
Set Room t ngt
SET Room t ngt
ACTUAL Room t
Back
room t hc2
DHW TEMP
SET DHW T DAY
SET DHW T DAY
