OPERATION

Menu structure

10 | WPM 3 www.stiebel-eltron.com

5.1 INFO menu

In the INFO menu you can compare the set and actual values for

temperatures, ﬂow rates and pressures of the heating system and

the heat pump.

Note

Please note that actual and set values can only be dis-

played if the appropriate sensors are connected.

5.1.1 INFO SYSTEM

Level 3

ROOM TEMPERATURE

ACTUAL TEMPERATURE FE7

Actual room temperature for heating circuit 1 (HC1) or heating cir-

cuit 2 (HC2)

(is only displayed if the FE7 remote control is connected)

°C

SET TEMPERATURE FE7

Set room temperature for heating circuit 1 (HC1) or heating circuit

2 (HC2)

(only displayed if the FE7 remote control is connected)

°C

ACTUAL TEMPERATURE FEK

Actual room temperature for heating circuit 1 or heating circuit 2

(is only displayed if the FEK remote control is connected)

°C

SET TEMPERATURE FEK

Set room temperature for heating circuit 1 or heating circuit 2

(is only displayed if the FE7 remote control is connected)

°C

RELATIVE HUMIDITY %

DEW POINT TEMPERATURE

Dew point temperature (is only displayed if the FEK remote control

is connected)

°C

HEATING

OUTSIDE TEMPERATURE °C

ACTUAL TEMPERATURE HK 1

Actual heating circuit temperature, heating circuit 1

°C

SET TEMPERATURE HK 1

Set heating circuit temperature, heating circuit 1 (HC1). With fixed

value control, the fixed temperature is displayed.

°C

ACTUAL TEMPERATURE HK 2

Actual heating circuit temperature, heating circuit 2

°C

SET TEMPERATURE HK 2

Set heating circuit temperature, heating circuit 1 (HK1). With fixed

value control, the fixed temperature is displayed.

°C

ACTUAL FLOW TEMPERATURE HP

Actual heat pump flow temperature

°C

ACTUAL FLOW TEMPERATURE NHZ

Reheating stages, actual flow temperature

°C

ACTUAL RETURN TEMPERATURE WP °C

SET FIXED TEMPERATURE °C

ACTUAL BUFFER TEMPERATURE

Actual buffer cylinder temperature

°C

SET BUFFER TEMPERATURE

Set buffer cylinder temperature

°C

HEATING PRESSURE bar

FLOW RATE l/min

SYSTEM FROST PROTECTION °C

DHW

ACTUAL TEMPERATURE

Actual DHW temperature

°C

SET TEMPERATURE

Set DHW temperature

°C

FLOW RATE l/min

Level 3

COOLING

ACTUAL TEMPERATURE FAN °C

SET TEMPERATURE FAN °C

ACTUAL TEMPERATURE AREA °C

SET TEMPERATURE AREA °C

SOLAR

COLLECTOR TEMPERATURE °C

CYLINDER TEMPERATURE °C

RUNTIME Hours

EXTERNAL HEAT SOURCE

ACTUAL TEMPERATURE °C

SET TEMPERATURE °C

DUAL MODE TEMP HZG

Heating dual mode point

°C

APPLICATION LIMIT HZG

Heating application limit

°C

DUAL MODE TEMP DHW

DHW dual mode point

°C

APPLICATION LIMIT DHW

DHW application limit

°C

RUNTIME Hours

ELECTRIC REHEATING

DUAL MODE TEMP HZG

Heating dual mode point

°C

APPLICATION LIMIT HZG

Heating application limit

°C

DUAL MODE TEMP DHW

DHW dual mode point

°C

APPLICATION LIMIT DHW

DHW application limit

°C

SOURCE

SOURCE TEMPERATURE °C

MIN SOURCE TEMPERATURE °C
