40 | WPM 3 www.stiebel-eltron.com
INSTALLATION
Commissioning
11.1.12 SENSOR CALIBRATION
Here, you can correct the displayed sensor temperatures.
ACTUAL FLOW TEMPERATURE WP
In menu item ACTUAL FLOW TEMPERATURE WP, you can correct
the temperature shown by +/-5 °C.
ACTUAL FLOW TEMPERATURE NHZ
In menu item ACTUAL FLOW TEMPERATURE NHZ, you can correct
the temperature shown by +/-5 °C.
ACTUAL RETURN TEMPERATURE WP
In menu item ACTUAL RETURN TEMPERATURE WP, you can correct
the temperature shown by +/-5 °C.
11.2 Setting parameters
The following lists the parameters that can be adjusted via the programming unit.
Note
Values in the "Setting range" and "Standard" columns will vary according to the connected heat pump type, and may deviate
from the indicated values.
Menu item Options Unit Min. Max. Standard System value
Programs / PART Y PROGRAM
HOURS 0 24
Programs / heat-up program
LOW END TEMPERATURE °C 20 40 25.0
DURATION BASE TEMP Days 0 5 2
MAXIMUM TEMPERATURE °C 20 50 40.0
MAX TEMPERATURE DURATION Days 0 5 0
RISE PER DAY K/day 1 10 1
Settings / general
CONTRAST 1 5 5
BRIGHTNESS % 0 100 50
TOUCH SENSITIVITY 1 10 4
TOUCH ACCELERATION 1 10 6
Settings / heating / heating circuit 1
COMFORT TEMPERATURE °C 5 30 20
ECO TEMPERATURE °C 5 30 20
MINIMUM TEMPERATURE OFF °C 10 30 OFF
ROOM INFLUENCE 0 20
HEATING CURVE RISE 0.2 3 0.6
HEATING CURVE VIEW
Settings / Heating / Heating circuit 2
COMFORT TEMPERATURE °C 5 30 20
ECO TEMPERATURE °C 5 30 20
MINIMUM TEMPERATURE OFF °C 10 30 OFF
MAXIMUM TEMPERATURE °C 20 90 50
MIXER DYNAMICS 30 240 100
ROOM INFLUENCE OFF 0 20
HEATING CURVE RISE 0.2 3 0.2
HEATING CURVE VIEW
