STIEBEL ELTRON WPM 3

36 | WPM 3 www.stiebel-eltron.com
INSTALLATION
Commissioning
11.1 COMMISSIONING menu
Note
All menu items are protected by a code and can only be
accessed and adjusted by a qualified contractor.
Note
Not all appliance parameters are displayed in the dif-
ferent menus, depending on which heat pump type is
connected.
Level 2 Level 3 Level 4
ENTER CODE
LANGUAGE
DEUTSCH
ENGLISH
FRANCAIS
NEDERLANDS
ITALIANO
SVENSKA
POLSKI
CESKY
MAGYAR
ESPANOL
SUOMI
DANSK
SLOVENSKO
RUSSKIA
NORSK
SOURCE
MIN SOURCE TEMPERA-
TURE
SOURCE MEDIUM ETHYLENE GLYCOL
POTASSIUM CARBONATE
EXTRACT MODULE 0
EXTRACT AIR MODULE
30
EXTRACT AIR MODULE
60
EXTRACT AIR MODULE
120
EXTRACT AIR MODULE
180
WATER
GROUNDWATER MOD-
ULE
HEATING
CONTROLLER DYNAMICS
HYSTERESIS
SPREAD CONTROL SET SPREAD
MAXIMUM PUMP RATE
STANDBY PUMP RATE
HEATING CIRC PUMP RATE
DHW
DHW CIRCUIT PUMP RAT-
ING
COMPRESSOR
MINIMUM DEFROST TIME
START DEFROST
IDLE TIME
MAXIMUM CURRENT
MINIMUM RUNTIME
HEATING SYSTEM SIZING DESIGN TEMPERATURE
HEAT DEMAND
CONSTANT OUTPUT
CONDENSATE RIBBON
HEATER
OUTSIDE TEMPERATURE
SINGLE PHASE OPERATION
QUICK START
SILENT MODE
FAN REDUCTION
OUTPUT REDUCTION OUTPUT
FAN
HEAT PUMP OFF
EMERGENCY OPER-
ATION
HEAT PUMP RESET
FAULT LIST RESET
SYSTEM RESET
SENSOR CALIBRATION
ACTUAL FLOW TEMPERA-
TURE WP
ACTUAL FLOW TEMPERA-
TURE NHZ
ACTUAL RETURN TEMPER-
ATURE WP
11.1.1 ENTER CODE
To change parameters you need to set the correct four-digit code.
The factory-set code is 1000
.
11.1.2 LANGUAGE
Here you can select the menu language.
11.1.3 SOURCE
Frost protection for ground source heat pumps.
MIN SOURCE TEMPERATURE
!
Material losses
Never operate the heat pump with source temperatures
below – 9 °C.
When set to OFF, the temperature at the source sensor is not
scanned.
If the actual temperature drops below the minimum source tem-
perature, the compressor is switched off and the idle time is set.
The compressor is enabled again after the idle time has expired
and the fixed hysteresis of 2 K has been exceeded.
This fault MIN SOURCE TEMP is indicated by a flashing warning
triangle on the display screen, and written to the fault list.
The source pump is always started 30 seconds earlier than the
compressor, which starts when there is a heat demand coming
from the heating or DHW side.
Note
The source pump runs on for 60 seconds after the heat
pump has been shut down.
