OPERATION
Appliance description
4 | WPM 3 www.stiebel-eltron.com
3. Appliance description
The second generation heat pump manager, also referred to as
WPM3, is responsible for the processes that control and regulate
all our heat pumps.
Connected heat pumps are controlled via the digital BUS connec-
tion that handles the bi-directional data exchange
Cascade control
Up to 6output stages can be controlled for heat generation.
The maximum permitted configuration for cascade control is sub-
ject to the type of heat pump you are using.
- 6 single compressor heat pumps
- 3 dual compressor heat pumps with identical compressors
- From the third connected heat pump upwards, an MSM must
be used to control the buffer charging pumps
Function overview
- The 4-wire data BUS enables rapid installation and system
extension using the MSM mixer module
- Control of a second heat source for DHW and heating
- 9 temperature inputs as set/actual value display
- Demand-dependent control of 7 different circulation pumps
- Input of the system and heat pump frost protection limits
- At least 10 h power reserve for the clock
- Automatic pump kick control
- Reset option
- Stored fault list with precise fault code indication on the dis-
play, including date and time
- Fast and precise fault diagnosis with system analysis, incl.
temperature scanning of heat pump and peripherals without
additional equipment.
- Default settings for time switch programs for all heating and
DHW circuits
- Solar differential controller
3.1 Heat pump types
Note
Heat pump type 5/5* cannot be connected directly to the heat pump manager.
 Use an indoor unit with integral WPM 3 heat pump manager for these heat pumps.
The description of individual functions varies between the different heat pump types. The types of heat pump are therefore identified
in this document as HP type 1 to 5 and 1* to 5*.
Heat pumps with second internal heat source
HP type 1 HP type 2 HP type 3 HP type 4 HP type 5
WPL 13, 18, 23 cool WPL 10 A / I / IK WPL 15 A(C)S WPL 33 HT WPL 08, 12, 16 S Trend
WPL 13, 18, 23 E WPL 33 WPL 20 A(C) WPL 33, HT (S) WPL 22, 28 Trend
WPL 13, 20 basic WPL 25 A(S)
WPL 13, 20 A basic WPL 25 AC(S)
WPL 13, 18 S basic WPL 07, 09, 17 ACS classic
WPL 10 AC WPL 19 I(K), WPL 24 I(K)
WPL 10 ACS
Heat pumps with second external heat source
HP type 1* HP type 2* HP type 3* HP type 4* HP type 5*
WPL 13, 18, 23 cool WPF-M 10, 13, 16 WPL 15 A(C)S WPL 33 HT WPL 08, 12, 16 S Trend
WPL 13, 18, 23 E WPW-M 13, 18, 22 WPL 20 A(C) WPL 33, HT (S) WPL 22, 28 Trend
WPL 13, 20 basic WPF 20, 27, 35, 40, 52, 66 WPL 25 A(S)
WPL 13, 20 A basic WPF 27 HT WPL 25 AC(S)
WPL 13, 18 S basic WPL 10 A / I / IK WPL 07, 09, 17 ACS classic
WPL 10 AC WPL 33 WPL 19 I(K), WPL 24 I(K)
WPL 10 ACS
WPL 34, 47, 57
