STIEBEL ELTRON WPM 3

OPERATION
Menu structure
www.stiebel-eltron.com WPM 3| 13
Level 2 Level 3
RIBBON HEATER
EXTERNAL COMPRESSOR ON
EXTERNAL FAULT
EX VALVE CENTRE POSITION
5.2.1 Fault list
The fault list provides an overview of the faults most recently
registered by the appliance. The fault list contains up to 20 fault
messages. The display, however, can show only 2. Scroll with the
scroll wheel to access the other entries in the fault list.
MAIN MENUDIAGNOSIS
FAULT LIST 1/1
01. SENSOR BREAK E 71
10:26 14JUN 14
02. MIN SOURCE
17:45 25JUN 13
5.2.2 Fault message
If the appliance registers a fault, this is clearly displayed with the
message shown below.
COMFORT MODE
!
FAULT
SENSOR BREAK E 71
TUESDAY 14JUN 14 16:27 TIME
If more than one fault occurs, the most recent fault is always
shown. Notify your qualified contractor.
5.2.3 Relay test
All relay outputs of the controller and heat pump can be individ-
ually switched from here.
5.3 PROGRAMS menu
All times for the heating, DHW, holiday and party modes can be
adjusted here. In addition, the heat-up program can be started.
Level 2 Level 3
HEATING PROGRAM
HEATING CIRCUIT 1
HEATING CIRCUIT 2
DHW PROGRAM
PARTY PROGRAM
HOURS
HOLIDAY PROGRAM
HOLIDAYS BEGINNING
HOLIDAYS ENDING
HEAT-UP PROGRAM
LOW END TEMPERATURE
DURATION BASE TEMP
MAXIMUM TEMPERATURE
MAX TEMPERATURE DURATION
RISE PER DAY
SILENT PROGRAM 1
SILENT PROGRAM 2
5.3.1 HEATING PROGRAM
In menu item HEATING PROGRAM you can determine when and
how often the appliance heats to the set comfort values for heating
circuit1 and heating circuit2. At all other times, the appliance
heats to the set ECO value. You can adjust the set values under
menu item SETTINGS / HEATING / HEATING CIRCUIT1 or HEAT-
ING CIRCUIT2. Below is an explanation of how to define a time
program.
First, select the days on which you want to enable the HEATING
function:
+
-
26�04�01�0301
Monday
Mon
MAIN MENU
PROGRAMS
HEATING PROGRAM
HEATING CIRCUIT 1
You can set your heating system as follows:
- For each individual day of the week (Monday - Sunday)
- Monday to Friday (Mon - Fri)
- Saturday and Sunday (Sat - Sun)
- the whole week (Mon - Sun)
Monday is initially offered.
 Scroll with the scroll wheel to select another day or group of
days.
 Confirm your selection with OK.
You can now set three switching time pairs. The three switching
time pairs are shown on the display, to the right of the clock. A
