Stihl MS 194 T User Manual

MS 194 T
English
17
Chain Saw Kickback Standard
The following standard apply with
respect to kickback:
– § 5.11 of ANSI/OPEI B175.1-2012
This standard, in the following referred
to as "the chain saw kickback standard"
sets certain performance and design
criteria related to chain saw kickback.
To comply with the chain saw kickback
standard:
a) Chain saws with a displacement of
less than 3.8 cubic inches (62 cm³)
– must, in their original condition,
meet a 45° computer derived
kickback angle when equipped with
certain cutting attachments,
– and must be equipped with at least
two devices to reduce the risk of
kickback injury, such as a chain
brake, low kickback saw chain,
reduced kickback bar, etc.
b) Chain saws with a displacement of
3.8 cubic inches (62 cm³) and
above
– must be equipped with at least one
device designed to reduce the risk
of kickback injury, such as a chain
brake, low kickback saw chain,
reduced kickback bar, etc.
The computer derived angles for chain
saws below 3.8 cubic inches (62 cm³)
displacement are measured by applying
a computer program to test results from
a kickback test machine.
WARNING
The computer derived angles of the
chain saw kickback standard may bear
no relationship to actual kickback bar
rotation angles that may occur in real life
cutting situations.
In addition, features designed to reduce
kickback injuries may lose some of their
effectiveness when they are no longer in
their original condition, especially if they
have been improperly maintained.
Compliance with the chain saw kickback
standard does not automatically mean
that in a real life kickback the bar and
saw chain will rotate at most 45°.
WARNING
In order for chain saws below 3.8 cubic
inches (62 cm³) displacement to comply
with the computed kickback angle
requirements of the chain saw kickback
standard use only the following cutting
attachments:
– bar and saw chain combinations
listed as complying in the
"Specifications" section of the
instruction manual or
– other replacement bar and saw
chain combinations marked in
accordance with the standard for
use on the chain saw or
– replacement saw chain designated
"low kickback saw chain."
See the section on "Low Kickback Saw
Chain and Reduced Kickback Bars."
Devices for Reducing the Risk of
Kickback Injury
Stihl recommends the use of green
labeled reduced kickback bars and low
kickback saw chains on your chain saw
equipped with a Stihl Quickstop chain
brake.
WARNING
To reduce the risk of injury, never use a
chain saw if the chain brake does not
function properly. Take the chain saw to
your local STIHL servicing dealer. Do
not use the chain saw until the problem
has been rectified.
STIHL Quickstop Chain Brake
STIHL has developed a saw chain
stopping system designed to reduce the
risk of injury in certain kickback
situations. It is called a Quickstop chain
brake.

Stihl MS 194 T Specifications

General

Idle speed	- RPM
Chain pitch	1/4 \
Blade length	350 mm
Product color	Black, Grey, Orange
Chain tensioner	Yes
Motor speed (max)	10500 RPM
Fuel tank capacity	0.266 L
Engine displacement	31.8 cm³
Power source	Gasoline
Sound power level	112 dB
Vibration emission	3.6 m/s²
Sound pressure level	100 dB
