Truck steering direction
D
F
BB
OM2313
CE
AA
H
G
Use the tiller to steer during travel.
●
When the tiller is turned anti-clockwise (G)
while travelling towards (A), the truck steers
towards (C)
●
When the tiller is turned anti-clockwise (G)
while travelling towards (B), the truck steers
towards (D)
●
When the tiller is turned clockwise (H) while
travelling towards (A), the truck steers to-
wards (E)
●
When the tiller is turned clockwise (H) while
travelling towards (B), the truck steers to-
wards (F)
Use
4
Using the truck
9745758043484 EN - 11/2021 - 08
