Tiller
Tiller positions
Position the tiller in accordance with the
truck functions
With the truck stopped, the two following tiller
positions are available:
●
Position (1) = working position.
In this position, the operator can begin trav-
el using the throttle.
In this position, the operator can begin lift-
ing or lowering the forks using the appropri-
ate throttle.
In this position, the operator can raise or
lower the straddles; for versions with strad-
dle initial lift only.
●
Position (2) = braking position.
In this position, the drive is locked and the
parking brake is engaged.
NOTE
●
In this position, lifting and lowering of the
forks and straddles, if fitted, is blocked.
NOTE
When the tiller is released, it automatically re-
turns to position (A), the braking position.
OM2277
A
1
2
2
OM2285
1
2
2
A
Overview
3
Tiller
4345758043484 EN - 11/2021 - 08
