Still EXV 14D - Safety Devices; Location of Safety Devices

Safety devices
Location of safety devices
Main safety devices on the truck
OM2308
10
1
2
3
3
4
5
6
7
8
9
10-11-12
11
13
14
Emergency shutdown handle.
Tiller position sensor. The truck will not
move if the tiller is not in the correct usage
position.
1
2
Operator anti-crush safety button. Protects
the operator from potential crushing by brak-
ing the truck.
Operator side protection. Prevents the oper-
ator from falling from the platform during
ride-on driving (if present).
3
4
Safety
2
Safety devices
2345758043484 EN - 11/2021 - 08
