CAUTION
Risk of loss of warranty.
Only a technician authorised by the service centre
may replace this battery.
Straddle automatic lowering (op-
tional)
This option is available for all trucks with
straddle initial lift (excluding the double pallet
stacker truck version).
For the standard version, when the straddles
are raised off the ground, if the operator tries
to raise the forks more than approximately
1800 mm from the ground, a message will ap-
pear on the display to warn that the operator
must lower the straddles to be able to raise
the forks any further (see
āā
Chapter "Display",
Page 32 ). The forks are locked at 1800 mm
from the ground until the operator lowers the
straddles.
If the truck is equipped with the "Straddle au-
tomatic lowering" option, the truck automati-
cally lowers the straddles (if raised off the
ground) during the fork lifting operation.
NOTE
On the version with platform, the automatic
function is intentionally blocked for safety rea-
sons when the operator guides the truck from
the ground in pedestrian mode. In this case,
the truck behaves in the same way as the
standard version. With ride-on driving, the au-
tomatic function operates normally.
Overview
3
Options and variants
72 45758043484 EN - 11/2021 - 08
