Still EXV 14D - Page 169

4.3
4
Aisle width with pallets
800 x 1200
Ast (
mm)
2588
(6)
2592
(6)
2605
(6)
4.3
4.1
Aisle width with pallets
1000 x 1200
Ast (
mm)
2559
(6)
2566
(6)
2587
(6)
4.3
5
Turning radius
Wa (
mm)
1715
(6)
PERFORMANCE EXP 14 EXP 16 EXP 20
5.1
Travel speed with/with-
out load
km/h 6.0 / 6.0
5.2
Lifting speed, with/with-
out load
m/s 0.16/0.30
(8)
0.15/0.30
(8)
0.15/0.30
(7)
5.3
Lowering speed, with/
without load
m/s 0.40/0.35
(8)
0.40/0.35
(8)
0.31/0.31
(7)
5.8
Climbing ability KB 5',
with/without load
% 8 / 23
(9) (10)
5.10 Service brake Electromagnetic
TRANSMISSION EXP 14-16-20
6.1 Traction motor, S2=60 min kW 2.3
6.2 Lifting motor, S3=15% kW 3.2
6.3
Battery acc. to DIN 43
531/35/36 A, B, C, no
3 PzS
(10)
6.4 Voltage/Nominal capacity V/Ah 24/345
6.5 Battery weight (±5%) kg 288
OTHER EXP 14-16-20
8.1 Type of drive control AC control
8.4
Noise level at operator's
ear
dB
(A)
≤ 66
(1) With Tele and NiHo mast +26 mm
(2) With Tele and NiHo mast -26 mm
(3) In brackets (truck with tandem rollers)
(4) Value with Triplex mast h3 = 4266 mm
(5) Value with Triplex mast h3 = 4026 mm
(6) Without creep speed +12 mm
(7) Value with Tele mast h3 = 3584 mm
(8) Value with Tele mast h3 = 4644 mm
Technical data
6
Datasheet
15945758043484 EN - 11/2021 - 08
