Fork Carriage Width b3 (mm) 1480
Ground Clearance below Mast(laden) m1 (mm) 145
Ground Clearance at Centre of Wheelbase(laden) m2 (mm) 180
Working aisle width with pallet 1000 x 1200 cross-
ways****
Ast (mm) 4557
Working aisle width with pallet 800 x 1200 cross-
ways****
Ast (mm) 4757
Turning Radius Wa (mm) 2795
Turning Point Minimum Distance from the Truck Cen-
ter Line
b13 (mm) 922
Performance data
Driving speed (with/without load) km/h 24/26
Lifting speed (with/without load) m/s 0.47/0.53
Lowering speed (with/without load) m/s 0.43/0.36
Drawbar Pull Tractive Effort (at 2km/h) with/without
load
KN 24/21
Gradeability (at 2km/h) laden/unladen % 20/20
Acceleration time, laden S 5.7
Acceleration time, unladen S 4.9
Service Brake Mechanical/Hydraulic
Engine
Engine Type DOOSAN P34
Engine Power in compliance with ISO 1585 kW 55.2
Rated Number of Revolutions rpm/min 2300
Cylinder Number/Displacement cm
3
4/3400
Emission level according to EU-regulation 2016/1628 Stage V
Fuel consumption according to VDI 2198-2019
（EN16796）
kg/h 6
Vehicle electrical system voltage V 12
Others
Drive Control Type
Electronic Hydraulic
torque convertor
Operating pressure for attachments bar 200
Oil volume for attachments l/min 108
Sound pressure level at the driver's seat EN12053 dB(A) 86
Sound power level during the workcycle EN12053 dB(A) 110
Full body vibration acceleration acc to EN13059 m/s2 1.66
Towing coupling, type DIN15170 Bolt
Technical datasheet
6
VDI Datasheet for RCG40
152 60118011601 EN - 09/2020
