Still RCG40 - VDI Datasheet for RCG40

VDI Datasheet for RCG40
NOTE
This VDI data sheet specifies only the techni-
cal values of the truck version with standard
equipment. Different tyres, lift masts, addition-
al units etc. may produce different values.
Characteristics
Manufacturer STILL
Model RCG40
Power type：Electric-Diesel-Petrol-LPG-Network
Power (Electric)
LPG
Operation Type: Hand-stand on-Driver seated Seated
Load Capacity Q (kg) 4000
Load centre of gravity distance c (mm) 500
Axle centre to fork face x (mm) 562
Wheel Base y (mm) 2000
Weights
Service Weight Kg 6800
Axle loading, laden front/rear Kg 9550/1250
Axle loading, unladen front/rear Kg 3340/3460
Wheels, chassis frame
Tyres:SE-Super elastic PN-Pneumatic SE solid tyre
Front Tyres Size 300*15/20PR
Rear Tyres Size 7,00-12/12PR
Front Track Width b10 [mm] 1180
Rear Track Width b11 [mm] 1190
Dimension and overall sizes
Mast lift, forward/backward α/β 6°/12°
Mast Minimum Overall Height h1 [mm] 2390
Free lift h2 [mm] 150
Lift height h3 [mm] 3000
Mast Maximum Overall Height h4 [mm] 4275
Overhead Guard Height h6 [mm] 2260
Seat Height h7 [mm] 1315
Drawbar Height h10 [mm] 390
Overall Length I1 (mm) 4186
Length to Face of Forks I2 (mm) 3116
Overall Width b1 [mm] 1485
Fork Arm Dimensions s/e/l (mm) 50/150/1070
Fork Carriage in Compliance with ISO 2328 Class/
Form A,B
III A
Technical datasheet
6
VDI Datasheet for RCG40
15160118011601 EN - 09/2020
