Check the engine oil level
NOTE
Check engine oil level with the engine cold
and the forklift on level ground.
Open the bonnet.
– Extract the dipstick (1) and clean it with a
clean cloth.
– Fully re-insert the dipstick.
– If the dipstick doesn't slide in, rotate it 180°
and try again.
– Remove the dipstick. The oil level should be
between the Max level (A)and Min level (B)
on the dipstick.
CAUTION
Risk of engine damage!
Insufficient engine lubrication can cause engine dam-
age. An insufficient oil level or the use of engine oil
with different specifications can lead to the failure of
engine lubrication.
– – Only use engine oil in line with the supply table.
– Add oil to the max oil level if the oil level is
below the Min level.
– Check condition of engine oil. If it is pollu-
ted, replace it with new oil.
– Fully re-insert the dipstick.
– Close the bonnet.
Use and Operation
4
Remaining ready for operation
56 60118011601 EN - 09/2020
