SatLink VSAT User Guide
Publication no. 101557
Copyright © 2009 – STM Group, Inc.
Page 101 (160)
Field Explanation
RF to B-band offset
Total frequency error introduced by the LNB, and receiver
analogue front-end in Hz.
AGC Status
Status of the AGC. Either enabled or disabled.
In normal operating mode the AGC state shall always be
Enabled.
AGC Gain
Gain applied to the RX chain by the AGC function.
RX Lband Input Level
Unit RX composite input level.
• dvb mesh show –config
This command displays the main mesh configuration as received in mesh logon response in addition
to two local status parameters (mesh capability and DLCP client state). Dynamic Link Control
Protocol is the protocol used by the VSAT and the hub for mesh operation. The client part of DLCP is
implemented in the VSAT. The server part implemented in the hub, DLCP server, is also called mesh
controller.
An example of mesh configuration after successful mesh logon:
#dvb mesh show -config
Satellite Mesh Configuration
--------------------------------
Mesh capability : Enabled
DLCP client state : Connected
Mesh Controller IP Address : 10.10.11.30
Mesh Controller DLCP UDP Port : 49359
Satellite Subnet ID : 1
Satellite Subnet Name : Mesh Subnet 1
Mesh Controller DLCP MCAST Group : 234.5.6.7
Default GW Address : 10.10.46.25
DLCP Version : 1
Mesh Address Space
--------------------------------
IP Address Subnet Mask
10.10.46.0 / 255.255.255.0
10.10.47.0 / 255.255.255.0
10.10.48.0 / 255.255.255.0
10.10.49.0 / 255.255.255.0
10.10.50.0 / 255.255.255.0
Hub Address Space
--------------------------------
IP Address Subnet Mask
10.10.11.0 / 255.255.255.0
The explanation of the displayed parameters is given in the following table:
Field Explanation
Mesh capability
Enabled by default. Possible values: enabled, disabled
DLCP client state
State of the client controlling mesh operation. One of the
following values: Initialisation, Logon Requested, Logon in
progress, Connected, Logon denied.
Mesh Controller IP address
The IP address of the mesh controller, also called DLCP
server.
Mesh Controller DLCP UDP port
The UDP port used for reception and sending DLCP
messages.
