SatLink VSAT User Guide
Publication no. 101557
Copyright © 2009 – STM Group, Inc.
Page 124 (160)
Example 2:
Define an access type with name “user”, with read-only maximum access and with restriction to the
10.10.20.0 sub-net for the SNMP request source.
# device snmp community user ro 10.10.20.0 255.255.255.0
# device snmp show
SNMP management access:
-----------------------
Community String Access IpAddress Subnet
normal-user Read only 10.10.20.0 255.255.255.0
public Read/Write 0.0.0.0 0.0.0.0
Example 3:
Remove the access type with name “user”.
# device snmp delcommunity user
# device snmp show
SNMP management access:
-----------------------
Community String Access IpAddress Subnet
public Read/Write 0.0.0.0 0.0.0.0
Example 4:
Only allow SNMP access from subnet 10.10.10.0/255.255.255.0 via the satellite interface.
# device manager add snmp 3 10.10.10.0 255.255.255.0
# device manager show
Management access:
------------------
Access Interface IpAddress Subnet
SNMP 3 10.10.10.0 255.255.255.0
E.5 Setting a MIB object and saving the configuration
When the STM SatLink VSAT is shipped from the factory, the essential MIB objects of the VSAT MIB
are given default values.
When changing the value of a MIB object with write access, the new value will in general be activated
when they are set. The value will apply as long as the STM SatLink VSAT is powered on. If no special
action is taken to save the new MIB value, the value will revert to the default value upon power-on.
To save a new value so that it will survive a VSAT power off/on, one must explicitly issue a MIB save
command by setting the MIB object sysCmdSaveConfig to 1.
Saving the configuration can take up to 20 seconds.
