MAC address is also shown on the CLI message displayed during the boot procedure of the STM SatLink
VSAT.
Example:
# device show
System Information:
Name : SatLink 2000
Location : UAE
Contact : STM UAE
System Up time : 0 days, 00:01:18
System time(UTC) : not set, TDT not received
HW:
Model : SatLink 2000
HW ID : 120033
Main board ID : 120026 R3.3
MAC addresses:
Ethernet (LAN) : 00:20:0e:10:35:34
Satellite (DVB) : 00:20:0e:10:35:34
Then do the following: -
1) If the receiver is not already on, Click Configuration on the SatLink VSAT home page and Start the
receiver by clicking on the Start button to acquire the forward link.
Figure 23 : Rceiver Configuration
