SatLink VSAT User Guide
Publication no. 101557
Copyright © 2009 – STM Group, Inc.
Page 43 (160)
9.2.1 Antenna and ODU Parameter Configuration
The STM SatLink VSAT is normally pre-configured to be used together with the STM SatLink 403x
Transceiver. The CLI command
odu show will show the ODU configuration with the two parameters,
ODU transmitter type and ODU receiver type, both set to STM SatLink 403x.
It is possible to configure the STM SatLink VSAT to operate together with other transmitters and
receivers than SatLink 403x. The valid ODU transmitters (BUC) are listed in Table 3 and the valid ODU
receivers (LNB) are listed in Table 5 (the list is also available using the CLI help command
? odu txtype). Choosing the ODU transmitter to be STM SatLink 403x will automatically lock the
ODU receiver type to STM SatLink 403x.
Please make sure that the correct ODU transmitter (BUC) type is selected according to the table below, as
the return link communication will not work otherwise.
ODU
Transmitter #
(type)
ODU Transmitter (BUC) STM Product Number
(P/N)
HW Revision
Ku-band
11 STM SatLink 403x 106546 (SatLink 4035) All
104804 (SatLink 4033) All
20 Norsat 1010XRT / 1020XRT All
30 Invacom TUL-204 104041 All
42 JRC NJT5096 All
43 JRC NJT5097 All
45 JRC NJT5017 All
65 ND SatCom RFT 35W All
71 CODAN 6908 w/ext All
75 Actox ABAxKUS All
C-band
80 JRC NJT5652 105268 All
81 JRC NJT5656 105269 All
92 Zinwell ZTX-C3300F 105701 All
90 Zinwell ZTX-C3301F 105276 All
93 Zinwell ZTX-C3700F 105700 All
91 Zinwell ZTX-C3701F 105274 All
Table 3: Overview of supported ODU transmitters (BUCs)
To configure use of an ODU transmitter (BUC) listed in the table above, please enter the CLI command
odu txtype <type> where type is the number from the first column in the table above.
Example:
# odu txtype 45
Selects the JRC NJT5017F transmitter. Use the command odu show to view the ODU configuration
parameters.
