When using the STM SatLink 4033/4035 Transceiver, the STM SatLink VSAT must be configured with
the antenna type in use in order to calculate the transmitted EIRP correctly. The following antennas are
supported:
Antenna #
(type)
Antenna (Ku-band) Size
21 ASC Signal Type 1.00m
2 Andrew Type 960 0.96 m
1 Andrew Type 123 1.20 m
5 Andrew Type 184 1.80 m
7 Andrew Type 244 2.40 m
11 Patriot TX-090KU 0.96 m
12 Patriot TX-100KU 1.00 m
13 Patriot TX-120KU 1.20 m
14 Patriot TX-240KU – BATWING 2.40 m
15 Prodelin Series 1132 1.20 m
16 Prodelin Series 1184 1.80 m
17 Prodelin Series 1250 2.40 m
18 Seatel 2406 0.6m
19 Seatel 4006 1.0m
20 Seatel 6006 1.5m
22 Raven G98 0.98m
6 Visiosat 0.75m
8 Seatel 4003 1.00 m
9 Visiosat KIT 90 EMIT 0.90 m
10 Visiosat KIT 120 EMIT 1.20 m
Table 4: Overview of supported Antenna types
Please see Appendix G (Table 9) for more detailed information regarding the antennas that can be used
with the STM SatLink 403x transceiver.
The STM SatLink VSAT is normally pre-configured to use the Patriot 0.96m antenna. If another antenna
listed in the table above is to be used, please enter the CLI command
odu antenna <type> where
type is the antenna number from the first column in the table above.
Example:
# odu antenna 13
selects the Patriot 1.2 m antenna. Use the command odu show to view the ODU configuration
parameters.
