SatLink VSAT User Guide
Publication no. 101557
Copyright © 2009 – STM Group, Inc.
Page 45 (160)
Example:
# odu show
Antenna Configuration
---------------------
Type Patriot TX-090KU - 0.9m
Tx Gain at 14.25 GHz 40.9dB
Transmitter (BUC) Configuration
-------------------------------
Type STM SatLink 4033 (14.0-14.5 GHz)
ODU Serial No. 104804030303051100020000
ODU HW Version 3.3
ODU SW Version 1.3
Local oscillator 13.050000 GHz
24V DC supply On
Receiver (LNB) Configuration
----------------------------
Type STM SatLink 403x (10.70-12.75
GHz)
Local oscillator - High band 10.600000 GHz
Local oscillator - Low band 9.750000 GHz
Oscillator switching frequency 11.700000 GHz
LO Switching mode 22kHz
13/18V DC supply 13V
The SatLink VSAT can be configured with one of the following LNBs:
ODU LNB #
(type)
ODU LNB STM P/N
Ku-band
20 Invacom SPV-1SM 100816
30 Zinwell ZK-VJ1 104730
40 JRC NJR2535S
41 JRC NJR2536S
42 JRC NJR2537S
43 JRC NJR2183F
C-band
80 Zinwell ZC-VD1 105267
85 Norsat 8000-series
Table 5: Overview of supported ODU receivers (LNB)
Enter the CLI command
# odu lnb <lnbtype> where lnbtype is the number from the first column
in the table above to configure the correct LNB.
When ODU BUC is chosen to be the STM SatLink 403x transceiver, the LNB will
automatically be set to STM SatLink 403x. The STM SatLink IDU will detect the STM
SatLink transceiver model being used (i.e. STM SatLink 4033, or 4035) and display the
detected model in the ODU Transmitter (BUC) Type field in the CLI
odu show output.
