LEMO port) and computer (by a serial and USB port) used for transferring the static data,
setting the receiver, updating the firmware and the license.
Fig. 3.9 - Multi-function communication cable
Auxiliary cable
External power supply cables can be ordered and used to connect an external battery (red and
black clips) to the receiver (small 5-pin LEMO)：
Fig. 3.10 - External power supply cables
