since in static mode there is no green light blinking.
- Press I key when the chosen light is blinking and the receiver will start in the selected
working mode. Summary of data link types:
4. Internal UHF Radio
5. GPRS\GSM module
6. External radio
Fig. 4.4 - S8 summary of data-link led
The next time you will switch on again the receiver, the working mode and data-link will be the
last selected.
If you prefer, you can select the correct data-link by handheld software.
As regards the advanced working parameters, for instance sampling interval, minimum
elevation angle, antenna height, etc, they can be set by handheld software or by Assistant,
without modifying the parameters the receiver will work with default parameters.
The static mode parameters cannot be selected by the controller, but only by Assistant.
IV.3 Standard operation of leds
Static mode
The STATIC and power led will keep lighted. When satellites fulfill the conditions (at least 4 GPS
or 4 GLONASS satellite), receiver will start recording epochs, you will hear a beep, STATIC light
will flash according to sampling interval (if you don’t set up, the default is 5 seconds) and the
satellite light will flash a number of times equal to the locked satellites.
