Fig. 5.15 - UHF Radio Settings
Frequency setting: insert the frequency, expressed in MHz, of the radio link associated to each
channel. There are 8 channels available in the internal UHF radio .
Channels: Selected the “default” Radio channel active after power on .
Power mode: Select the transmission power level low (0,5 Watt) or high (1 Watt).
Please note that Protocol and Spacing option cannot be modified, they are “TrimTalk GMSK”
and 25 KHz.
Click on button “OK” to confirm your choice.
V. 2.3.3 External
This option give us the possibility to use an external device, usually an external UHF Radio
connected by cable at lemo-5 connector.
If you select “External” and Click on “Settings”, a new form will open and in this form you can
