ISP Immersive Sound Processor
15
G. At the end, a summary of the Speakers
Configuration is shown. A four digits
description is given following this order:,
“Base Layer . LFE . Height Layer . Top Layer”.
H. Save to exit and reach the Speakers
edition page loaded with the default
audio profile “New profile 1”.
Zones
Zones are mono or stereo, and with or without
video output or can be dedicated to headphone
playback when used with an external headphone
amplifier. Stereo Audio/Video and Headphone
Zones include provisions for adjusting lip sync.
Audio only zones do not. Zones occupy unused
channels and can play concurrently with a
theater or without one. Note that system wide,
you can select one input for the main theater
(Main Source) and one Zone 2 input used by all
the audio zones (Secondary source). You can
1. Rename
You can rename a profile
2. New
Click New to build a new fresh profile.
3. Duplicate
Build a variation of a saved profile. For
instance, you cannot edit Dirac reference
profiles directly although it can be useful to
tune levels of replicated speakers. In such
case, create a duplicate of the reference
profile and edit it to adjust the needed
parameters.
4. Save
After any changes to a profile are made or
creation of a new one, you must SAVE your
changes.
position, depending on the base layer
definition. Keep «None» for normal
down-firing in ceilings speakers.
E. For each speaker, you can define whether
replication is required. Use this feature
for multiple subwoofers or multiple rows
of surround speakers declaration or any
speaker you wish to replicate. In case
there is no subwoofer in the system,
please select “0” in the subwoofer row.
F. Press Next to reach the next layer and
follow again steps A to E until all three
layers are defined.
G H
1
2
3
4
choose the Zone to play either the Zone2 source
or follow the Main Theater source. Zones have all
the same features of a main theater except that
channels are always “large”, they cannot include
subwoofer channels, and they are limited to
mono or stereo. In order to control a zone, it
must be included in the preset that is currently
selected in the remote control. See “Presets” on
page 32 for more details.
Profiles
For each Theater, Sub-Theater, and Zone, there is
a default profile created. You can save multiple
profiles for different listening preferences with
specific speakers settings (such as different EQ
profiles based on content type).
Profiles can be recalled as part of presets (see
“Presets” tab, page 32). A profile includes: Speaker
definition (multi-way, levels, delays), bass
management, manual EQ, and Dirac filter design
if applied.
