Strand 301 Console Manual Page 21
Timed Events Mode
Capacity
There are 12 timed events that can be recorded. The events are triggered using the internal
system clock. Timed events may be played back in any order.
Changing Modes
To change to timed event mode, hold down BOTH the up and
down keys simultaneously for 3 seconds. A list will appear on the
LCD screen.
Navigate with the up and down keys to pick the Events Player.
Notice the flashing cursor on the current selection. When the
cursor is on the appropriate mode, press Confirm to accept.
Screen Menus for Events Player
Main Screen -
This is the event player mode’s main screen menu.
Information on this screen is as follows…
Time – console’s internal clock. (Can be set in the Menu.)
Event Stop – this indicates that no event is currently running.
Ch – this indicates the channel that had the last action.
LL – this indicates the last action channel’s level.
Start - this button will allow the console to start the next scheduled event.
<Ms> - this lets the operator know that the console is in master mode rather than slave
mode. With a single 301, this should always be Ms.
Menu – allows the operator to adjust setup options and delete items specific to the current
mode.
Menu -
Menu – this allows access to the event player menu that deletes events, sets default fade
time and sets buzzer and clock.
Delete Event – gives the operator the delete event options.
Set Default Fade Time – allows the operator to set the default fade
time. (The maximum is 59:59)
Set Buzzer - allows the operator to either Enable or Disable the
buzzer.
There is a fourth item that is not initially visible. Use the up / down keys to access it.
Set Clock – allows the operator to set the internal clock.
12:00:00
Event Stop
CH:01 LL:00
Start <Ms> Menu
1. Delete Event
2. Set Default Ft
3. Set Buzzer
Quit +/- Confirm
1. Back Up
2
. Events Player
3. 12 Ch Control
Quit +/- Confirm
4. Set Clock
Quit +/- Confirm
