Page 28 Strand 301 Console Manual
- Patch
Patch – this allows the operator to view and change the
assignment of dimmers to control channels of the console.
Edit
Patch
Edit Patch – allows the operator to edit the patch. Navigate the
up / down keys to select Edit Patch. Then press Confirm.
Press the up / down keys to select the dimmer who’s
channel assignment wants to be edited. Then press the
bump button under the channel to assign the dimmer
number to that channel.
The edit patch screen above shows dimmer 27 assigned to channel 2. As the up / down
keys move through the dimmer list numerically, it will show the current channel assignment
for all dimmers. Any dimmer that shows an assignment of Ch:XX, means that dimmer has
no channel assignment and therefore will not be controlled by the console until an
assignment is made in patch.
To display all unpatched dimmers, go to Display Patch and view channel 0. See the Display
Patch section in this manual for instructions.
Since this is a soft patch (which means it is an electronic patch), any number of 512 dimmers
can be controlled by any channel.
00 00 00 00
00 00 00 00
00 00 00 00
XFtm <Ms> Patch
1. Edit Patch
2. Display Patch
3. Default Patch
Quit +/- Confirm
Edit Patch
Bump Button=CH
Dmx:027
to Ch:02
Quit +/- Unpatch
