Strand 301 Console Manual Page 29
Display
Patch
Display Patch – allows the operator to view the patch by
channel. Navigate the up / down keys to select Display Patch.
Then press Confirm.
.
This screen displays that channel 1 has control of dimmer 1.
Press Quit and the console goes back to the
previous screen, but notice that the channel has
advanced to the next channel. Press Confirm
to see the next channel’s assignment.
Default
Patch
Default Patch – this allows the operator to take the console
back to a patch of 1 to 1. For all 12 channels, the dimmer
assignment will equal the channel number. Dimmers 13 – 512
will have no patch assignment.
To default the patch. Navigate the up / down keys to select
Default Patch. Then press Confirm.
To continue with the default patch command, press Confirm.
00 00 00 00
00 00 00 00
00 00 00 00
XFtm <Ms> Patch
1. Edit Patch
2
. Display Patch
3. Default Patch
Quit +/- Confirm
Display Patch
Select Ch:01
Quit +/- Confirm
CH 01= 001
Quit
Display Patch
Select Ch:02
Quit +/- Confirm
00 00 00 00
00 00 00 00
00 00 00 00
XFtm <Ms> Patch
1. Edit Patch
2. Display Patch
3. Default Patch
Quit +/- Confirm
Turn On Default
Patch?
Quit Confirm
