6. LoosenthescrewsecuringtheUVlampcover(A),andpullthecoverup
(B),thenout(C).
Figure6-109RemovingtheUVlampcover
7. PulltheUVlampreflectoroutoftheprintblock.
Figure6-110RemovingtheUVlampreflector
8. InspectthenewUVlampreflector,andmakesurethatablackstripis
attachedtotheinsideofit.Ifnot,installone—onthesideofthereflector
opposite(notnextto)theprintblock.
Note: ExtrablackstripsareincludedintheprinterStart-UpKit.Ifnecessary,
youcanremovetheblackstripfromtheoldreflectorandinstallitinthenew
reflector(aslongastheblackpainthasnotfaded).
9. DiscardtheoldUVreflectorandlamp.
DisposeoftheusedUVlampinaccordancewithenvironmentaland
safetyrequirements.
