Objet500 User Guide 5 Using Objet Studio
DOC-07027 Rev.E 5-9
Group Purpose When enabled Tray
Settings
Ribbon
Model
Settings
Ribbon

Settingmodel
dimensions.
Amodelis
selected.
 

Cutting,copying,pasting
anddeletingmodels.
Amodelis
selected.



Moving,rotatingand
resizingmodels.
Amodelis
selected.

 
• Assigningamaterial
toamodelorshell.
• Separatingamodel
intoshells.
Amodelis
selected.

 
Assigningmodelfinish
andsettingsupport
strength/“hollow.”
Amodelis
selected.

 
Settingamodel’sunitof
measure(millimetersor
inches).
Amodelis
selected.
 
Toquicklyidentifyanicon,movethecursoroverittodisplayatooltip.The“Undo”and
“Redo”tooltipschangetoreflectyourlastObjetStudioaction.
Afteractivatingsomeoftheribboncommands(byclickingthem),theyremainactiveuntil
youclickanotherbuttonoruntilyoupresstheEscapekey.
