Objet500 User Guide 5 Using Objet Studio
DOC-07027 Rev.E 5-20
Quick-Access
Model
Commands
Youcanaccesscommoncommandsforworkingwithobjectsonthebuild
traywiththeconvenientModelToolbarandcontextmenus.


ModelToolbar
SelectanobjectinthetraytodisplaytheModelToolbarthatcontainsicons
toperformcommontasks.
Figure5-18ModelToolbar
ThetablebelowdescribestheModelToolbaricons.
Icon Description
Appliesamattefinishtothemodel.
Appliesaglossyfinishtothemodel.
OpenstheAdvanced PropertiesdialogboxforsettingtheGrid
StyleandtheHollowoption.
Enablesdragginganobject(seepage5-39).
OpenstheTransformdialogboxforchangingtheobject’s
positionandscale.
TogglestheLockModelOrientationsetting.
Allowsyoutochoosetheprintingmaterials.
Enablesyoutoapplyacoatingtothemodel,orchangethe
coatingpreviouslyapplied.
Right-clickmodelmenu
Ifyouright-clickonanobject,apop-upcontextmenuisdisplayedfrom
whichyoucanalsoselectthemodelfinish,changeitspositionandscale,and
settheGrid StyleandHollowoptions.
YoucanalsocreateaQuickAccesstoolbarwithyourmostcommonly
usediconsgroupedtogether.See"CreatingaQuickAccessToolbar"on
page5-68.
