Strobel 441-1 - Abridged Version of Adjustment Manual

8 MA_441-1-2_A1_180830_en
2.5 Abridged version of adjustment manual
Setting value
Class
Dimensio
n
Needle type 134
Needle size 120 - 140
Stitch length
A
3 - 8
Loop stroke
B
5,5
Needle point front measured from plate edge
C
24
Needle bar eccentric stroke
E
32,4
Looper deflection to right from centre needle -
looper point
F
4,9
Looper deflection to left
G
10,2
Looper position front measured from plate edge
H
11,7
Looper position rear
J
6,2
Looper transition
K
10,5
Looper height incl. shaft
L
37
Rear end position / Position without needle
M
about 48.5
Rear end position / Position with needle
N
about 9.4
