4.17 Working with the control AB425
CAUTION!
Switch off the machine electrically!
4.17.1 Setting the stitch length
Function with V850 operating control Parameter
Stitch length setting F-711
In order for the machine to run synchronously, the stitch length needs to be
determined first. To do so, you take a Texon strip for example and feed the strip
between both plates, with the machine switched off, by turning the handwheel
until the needle has pierced 11 times. Afterwards you measure the distance of
the 11 piercings and enters this via the parameter "F-711".
Fig. 19
