Strobel 441-1 - Setting the Position 1 and 2

29 MA_441-1-2_A1_180830_en
4.14.2
After entering the code number "5913" and the button "E" for the technician
level:
Setting the position 1 and 2
- Select parameter F-171. Display shows:.1.7.1.
- Press the "E" button. Sr2_
- Press the ">>" button. P1E
Keep turning the handwheel in the machine's direction of
rotation until the display of "P1E" changes into the display of
the position value and then set the handwheel or needle to
the position 1 of the sewing machine (Fig. 17). Remember or
record the position value.
- Press the "E" button. P2E
Keep turning the handwheel in the machine's direction of
rotation until the display of "P2E" changes into the display of
the position value and then set the handwheel or needle to
the position 2 of the sewing machine (Fig. 18). Remember or
record the position value.
- Press the "E" button. P1A
Keep turning the handwheel in the machine's direction of
rotation until the display of "P1A" changes into the display of
the position value and then turn the handwheel until the
position value "P1E + 25" is displayed.
- Press the "E" button. Display shows: P2A
Keep turning the handwheel in the machine's direction of
rotation until the display of "P2A" changes into the display of
the position value and then turn the handwheel until the
position value "P2E + 25" is displayed.
- Press the "P" button. .1.7.1.
- Press the "P" button.
At least one cycle needs to be sewn so that the setting is saved before the
machine is switched off.
Needle positions
Parameter
Value
F-451
P1E
036
F-452
P1A
061
F-453
P2E
342
F-454
P2A
009
Starting point for the stepper motor
Parameter
Value
F-749
220
