4.13
With the control AB611 or AB425
Positions
Function
Parameter
Setting the reference position
F-170
This function sets the reference position.
Function
Parameter
Setting positions 1 and 2
F-171
This function sets the two positions.
The control has two positions. The positions are set exclusively by
programming the control.
A position is determined by a position input and output value. The values
correspond to the number of increments (steps), counted from an entered
reference position. A rotation is divided into 360 steps (increments) thereby, i.e.
1 step = 1 degree.
CAUTION!
In order to ensure a safe or proper sequence there should be at least 50
steps (increments) between two positions.
Furthermore there should be 25 steps between position input value and
output value of the same position (very important for internal functions of
the control).
For the precise programming of the individual positions refer to point "4.14
Setting the positions".
The setting of the positions can be easily checked using the F-172 function.
Refer to point "4.15 Display of the needle positions"
