Strobel 441-1 - Display of the Needle Positions; Sewing Drive

31 MA_441-1-2_A1_180830_en
4.15
Refer also to point "
Display of the needle positions
4.13 Positions"
Function Parameter
Display of the Positions 1 and 2
(down / up)
F-172
The setting of the positions can be easily checked using this function.
After entering the code number "1907" and the button "E" for the technician
level:
- Select parameter F-172. Display shows: .1.7.2.
- Press the "E" button. Sr 3
Turn the handwheel according to the motor's direction of rotation.
- Display at the control:
Segment 5 is switched on. ⇒ Position 1E
Segment 5 is switched off. ⇒ Position 1A
Segment 6 is switched on. ⇒ Position 2E
Segment 6 is switched off. ⇒ Position 2A
- Press the "P" button. .1.7.2.
- Press the "P" button.
4.16
Refer also to point "
Sewing drive
4.13 Positions"
The motor has its own operating instructions included which has information on
programming and circuit diagrams.
