7 MA_VEB100-2-4-5_A5-3_230123_en.doc
2.5.2 Mains voltage and frequency
CAUTION!
The range of the rated voltage and frequency for the sewing
drive is 190–240 V 50/60 Hz single-phase.
The mains voltage and frequency have to lie within this range!
2.5.3 Mains connection
CAUTION!
The sewing machine must be connected to the mains power
supply with a plug connection (power plug)!
A permanent connection is not permitted!
CAUTION!
The safety instructions in Chapter 1 must be observed when
connecting and laying the connection cables.
When laying the cables, ensure in particular that distance
is kept to movable parts (e.g. V-belts) and their mountings.
The mains cable may be fused with max. 16 A.
See also the circuit diagrams for the individual machine classes, which you will find
from point "5 Circuit diagrams".
Instructions on laying the cables:
Protect the mains cable being laid against any expected stresses and secure
adequately (incl. possible strain relief).
Lay and secure the mains cable so that it has a minimum distance of 25 mm to the
movable parts.
To ensure safe separation, it is preferable to lay the mains cables spatially apart from
other cables/low voltage lines. A rectangular crossing is better than one at a small
angle; avoid a parallel guide.
