Strobel VEB100 Series User Manual

19 MA_VEB100-2-4-5_A5-3_230123_en.doc
2.9.3 Class VEB100-5
Theoretic needle radius
41.3 mm
Left needle guide
41.33 +0.02 mm
Needle glide plate
41.30 ±0.01 mm
Right needle guide
41.40 +0.05 mm
Needle stroke, needle eye to looper finger
1.5 +0.5 mm
Looper stroke
18 +0.5 mm
Feed length
approx. 5 - 8 mm
Loop stroke
2.8 +0.3 mm
