33 MA_VEB100-2-4-5_A5-3_230123_en.doc
3.6 Pressure foot
3.6.1 Adjusting the pressure foot
A T T E N T I O N !
Switch off the machine electrically!
The position of the pressure foot is given by the position of the angle lever symmetrical
to the presser. It should tip lightly and lie evenly against the stitch plate. The pressure
foot pressure can be adjusted using separate screws for each stand on the upper side
of the material support arm.
3.6.2 Adjusting the lifting for the pressure foot (Fig. 16)
The pressure foot are pressed backwards when airing the material support arm. The
adjustable eccentric bolts serve as stops (5).
In the upper position of the material support arm, there must be approx. 2 mm
between the lever and bolts to ensure that the pressure foot presses securely against
the stitch plate for every position of stitch depth control.
