2.9 Brief setting instruction
2.9.1 Class VEB100-2
Theoretic needle radius
41.3 mm
Left needle guide
41.33 +0.02 mm
Needle glide plate
41.30 ±0.01 mm
Right needle guide
41.40 +0.05 mm
Needle stroke, needle eye to looper finger
1.5 +0.5 mm
Looper stroke
18 +0.5 mm
Feed length
approx. 5 - 8 mm
Loop stroke
2.8 +0.3 mm
2.9.2 Class VEB100-4
Theoretic needle radius
41.3 mm
Left needle guide
41.33 +0.02 mm
Needle glide plate
41.30 ±0.01 mm
Right needle guide
41.40 +0.05 mm
Needle stroke, needle eye to looper finger
1.5 +0.5 mm
Looper stroke
16 +0.5 mm
Feed length
2 - 5 mm
Loop stroke
2.1 +0.3 mm
