15 MA_VEB100-2-4-5_A5-3_230123_en.doc

Technischer Auslieferzustand / delivery condition:

Riemenscheibendurchmesser Maschine/

machine pulley diameter

dw 80 mm

Motor-Leistung min. / min. motor power

500 W

Keilriemen-Profil / V-belt profile

10 x 6 mm

Zahnriemenscheibe Maschine /

toothed belt pulley/machine

Z = 38

Zahnriemenprofil / toothed belt profile

HTD 5M-9

Stichart / stitch type

Einfaden-Kettenstich-Blindstich Typ 103 /

single thread chain stitch type 103

Anschluss pneumatisch / pneumatic connection

6 bar

Luftverbrauch, Mittelwert /

avarage air consumption

abhängig von der Ausstattung /

depending on the equipement

Stellfläche / foot print

0,5 m x 1,1 m

Arbeitsgeräusch / operating noise at 1800 min-1

nach DIN 45635-48-1 KL3

LpAm 70 dB(A)
