Strong SRT 5000 User Manual

For connection of the SRT 5000 there are number of
alternatives depending what is your preference and
the connection types on your TV.
Please connect by either of the following methods A.
B. C. (D. is mandatory for antenna connection)
IMPORTANT: Refer to Page 3 of the Instruction Manual
for the Connector Reference Numbers listed below.
12
How to Connect
If your TV includes a 4 Pin Mini Din S-Video
connector, you may choose to connect in this way.
Connector 7 SVHS S-Video
S-Video connector (connector 7) on the rear panel
and unit can be connected to the TV this way. (You
will need to purchase S-Video Lead separately)
Important: Using this separate S-Video (Y/C) for your
Video connection, you will need to make connections
for Audio.
For Audio, this can be done by using the supplied
RCA cable by connecting to Connector 9 for Right
Audio (RCA Red) and Connector 10 for Left Audio
(RCA White), and then connect to appropriate RCA
audio connectors of your TV.
These Left (white) & Right (Red) RCA Audio
connections will provide MPEGA-2 Stereo.
If you require Dolby Digital Audio Output (through
you’re Dolby Digital Decoder Amplifier) please refer to
Note: DOLBY DIGITAL AUDIO.
B. Separate S-Video (Y/C)
Connector
A. CVBS (Composite) via
the supplied RCA Lead
You can connect to your TV with the supplied RCA
cable to give you Video and Audio. This will give you
CVBS (Composite Video & MPEG-2 Stereo for Audio)
Connector 8
VIDEO (Yellow)
RCA cinch Composite video output
Connector 9
AUDIO Right (Red)
RCA cinch Right audio output
Connector 10
AUDIO Left (White)
RCA cinch Left audio output

Strong SRT 5000 Specifications

General

Brand	Strong
Model	SRT 5000
Category	TV Receiver
Language	English
